Time-based deployments with Flux Operator
We are thrilled to announce time-based deployments, a feature long-awaited by Flux users, in Flux Operator v0.23.0!
Organizations using Flux for GitOps deployments frequently require sophisticated control over when changes are applied to production systems, particularly in regulated industries or critical business environments. Key requirements include adhering to Change Advisory Board (CAB) approval windows, enforcing “No Deploy Fridays” policies, and restricting deployments during peak business hours to ensure service stability.
Maintenance windows become critical when managing helm upgrades, where teams need to skip reconciliation unless the current time falls within a specified interval. In regulated environments like medical device companies, automated deployments must be controlled to prevent unexpected disruptions during critical operational periods. Large telecommunications providers and ISVs managing multiple client clusters need gating mechanisms to control application rollouts, allowing tenants to consume platform updates when ready.
In this post, we show how to use time-based deployment with Flux Operator
ResourceSets
.
How it works
The Flux Operator ResourceSet API allows defining bundles of Flux objects by templating a set of resources with inputs provided by the ResourceSetInputProvider API.
The ResourceSetInputProvider API allows pulling inputs from external sources, such as
GitHub pull requests, branches and tags. For example, on the reconciliation of a
ResourceSetInputProvider of type GitHubTag
, the operator will list the tags of
a GitHub repository, filter them according to a semver range, and export a set of
inputs for each matching tag in the ResourceSetInputProvider .status.exportedInputs
field. For example:
status:
exportedInputs:
- id: "48955639"
tag: "6.0.4"
sha: 11cf36d83818e64aaa60d523ab6438258ebb6009
Starting with Flux Operator v0.23.0, the ResourceSetInputProvider API now has the field
.spec.schedule
,
which allows defining a cron-based schedule for the reconciliation of the ResourceSetInputProvider.
For example:
spec:
schedule:
# Every day-of-week from Monday through Thursday
# between 10:00 to 16:00
- cron: "0 10 * * 1-4"
timeZone: "Europe/London"
window: "6h"
# Every Friday from 10:00 to 13:00
- cron: "0 10 * * 5"
timeZone: "Europe/London"
window: "3h"
With this configuration, reconciliations of the ResourceSetInputProvider object
would only be allowed to run within the specified time windows. When the window
is active, the reconciliation happens normally, according to the interval defined
in the fluxcd.controlplane.io/reconcileEvery
annotation.
A complete example
- Define a ResourceSetInputProvider: This provider will scan a Git branch or tag for changes and export the commit SHA as an input.
- Configure schedule: The provider will have a reconciliation schedule that defines when it should check for changes in the Git repository.
- Define a ResourceSet: The ResourceSet will use the inputs from the provider
to create a
GitRepository
andKustomization
that deploys the application at the specified commit SHA.
ResourceSetInputProvider Definition
Assuming the Kubernetes deployment manifests for an application are stored in a Git repository, you can define a input provider that scans a branch for changes and exports the commit SHA:
apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSetInputProvider
metadata:
name: my-app-main
namespace: apps
labels:
app.kubernetes.io/name: my-app
annotations:
fluxcd.controlplane.io/reconcileEvery: "10m"
fluxcd.controlplane.io/reconcileTimeout: "1m"
spec:
schedule:
- cron: "0 8 * * 1-5"
timeZone: "Europe/London"
window: 8h
type: GitHubBranch # or GitLabBranch
url: https://github.com/my-org/my-app
secretRef:
name: gh-app-auth
filter:
includeBranch: "^main$"
defaultValues:
env: "production"
For when Git tags are used to version the application, you can define an input provider that scans the Git tags and exports the latest tag according to a semantic versioning:
apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSetInputProvider
metadata:
name: my-app-release
namespace: apps
labels:
app.kubernetes.io/name: my-app
annotations:
fluxcd.controlplane.io/reconcileEvery: "10m"
fluxcd.controlplane.io/reconcileTimeout: "1m"
spec:
schedule:
- cron: "0 8 * * 1-5"
timeZone: "Europe/London"
window: 8h
type: GitHubTag # or GitLabTag
url: https://github.com/my-org/my-app
secretRef:
name: gh-auth
filter:
semver: ">=1.0.0"
limit: 1
ResourceSet Definition
The exported inputs can then be used in a ResourceSet
to deploy the application
using the commit SHA from the input provider:
apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSet
metadata:
name: my-app
namespace: apps
spec:
inputsFrom:
- kind: ResourceSetInputProvider
selector:
matchLabels:
app.kubernetes.io/name: my-app
resources:
- apiVersion: source.toolkit.fluxcd.io/v1
kind: GitRepository
metadata:
name: my-app
namespace: << inputs.provider.namespace >>
spec:
interval: 12h
url: https://github.com/my-org/my-app
ref:
commit: << inputs.sha >>
secretRef:
name: gh-auth
sparseCheckout:
- deploy
- apiVersion: kustomize.toolkit.fluxcd.io/v1
kind: Kustomization
metadata:
name: my-app
namespace: << inputs.provider.namespace >>
spec:
interval: 30m
retryInterval: 5m
prune: true
wait: true
timeout: 5m
sourceRef:
kind: GitRepository
name: my-app
path: deploy/<< inputs.env >>
When the ResourceSetInputProvider
runs according to its schedule, if it finds a new commit,
the ResourceSet
will be automatically updated with the new commit SHA which will trigger
an application deployment for the new version.
