Bootstrapping Flux with Terraform, the right way

A Terraform module that bootstraps Flux Operator without fighting Flux for resource ownership, keeps secrets out of state, runs in the same root module as the cluster, and handles platform prerequisites that Flux itself depends on.
By Matheus Pimenta |
Tags:

Today we are excited to introduce a new Terraform module (fully compatible with OpenTofu) that bootstraps Flux Operator into a Kubernetes cluster and then gracefully steps aside, letting Flux do what Flux does best.

Here are some of the problems it sets out to fix.

Ownership handoff

Terraform is the natural place to install Flux right after a cluster comes up — credentials are in scope, providers are wired. The trouble starts the moment Flux is online: every object Terraform applied is now also an object Flux wants to reconcile. The traditional workaround — the fluxcd/flux provider, or chained helm_release resources — keeps Terraform on the hook for steady-state reconciliation forever.

This module flips that. Terraform owns only the bootstrap mechanism: a namespace, temporary RBAC, and a Kubernetes Job that applies Flux Operator and the FluxInstance with create-if-missing semantics. Once Flux adopts an object, Terraform stops touching it. When inputs are unchanged, terraform plan shows zero diff.

Same GitOps repository

The Terraform root module and the Flux manifests live side-by-side in the same repository, so the bootstrap inputs and the steady-state desired state are versioned together:

repo/
├── terraform/                             # Terraform root module
│   ├── main.tf
│   ├── providers.tf
│   └── variables.tf
└── clusters/
    └── staging/                           # reconciled by Flux via FluxInstance.spec.sync.path
        └── flux-system/
            ├── flux-instance.yaml         # applied by the bootstrap Job
            ├── flux-operator-values.yaml  # shared between Terraform and the Flux-managed HelmRelease
            ├── flux-operator.yaml         # ResourceSet wrapping the Flux Operator HelmRelease
            ├── runtime-info.yaml          # Git-managed fields of flux-runtime-info (optional)
            └── kustomization.yaml         # configMapGenerator for flux-operator-values

The Terraform module loads the same flux-instance.yaml that Flux will reconcile after bootstrap, and provisions the Git pull secret it needs to keep syncing the repository:

module "flux_operator_bootstrap" {
  source   = "controlplaneio-fluxcd/flux-operator-bootstrap/kubernetes"
  revision = 1

  gitops_resources = {
    instance_yaml = file("${path.root}/../clusters/${var.cluster_name}/flux-system/flux-instance.yaml")
  }

  managed_resources = {
    secrets_yaml = <<-YAML
      apiVersion: v1
      kind: Secret
      metadata:
        name: flux-system
      type: Opaque
      stringData:
        username: git
        password: '${var.git_token}'
    YAML
  }
}

And — importantly — no secret material ever lands in the Terraform state file. The module marks managed_resources as sensitive and only persists a SHA-256 hash to detect changes, while still reconciling drift on every run with server-side apply — the same model as kustomize-controller. Pull values from Vault, AWS Secrets Manager, or any other store via data sources and compose them into secrets_yaml; the rendered YAML never appears in state.

Same root module as the cluster

The module does not require cluster connectivity at plan time, so it lives in the same Terraform root module that creates the cluster — no two-phase apply, no provider chicken-and-egg:

module "cluster" { source = "..." }

provider "helm" {
  kubernetes = {
    host                   = module.cluster.endpoint
    cluster_ca_certificate = base64decode(module.cluster.ca_certificate)
    token                  = module.cluster.token
  }
}

module "flux_operator_bootstrap" {
  depends_on = [module.cluster]
  source     = "controlplaneio-fluxcd/flux-operator-bootstrap/kubernetes"
  revision   = 1
  # ...
}

Platform prerequisites Flux depends on

Some components have to exist before Flux can run — a self-managed CNI like Cilium being the canonical example, since without it no pod gets networking, including the Flux controllers themselves. The module accepts an ordered list of prerequisite Helm charts and manifests, which are applied by the bootstrap Job before Flux Operator. For the CNI case the Job can run with host_network: true, since pod networking is unavailable until the CNI is up:

job = {
  host_network = true
}

gitops_resources = {
  instance_yaml = file("${path.root}/../clusters/${var.cluster_name}/flux-system/flux-instance.yaml")
  prerequisites = {
    charts = [
      { name = "cilium", repository = "quay.io/cilium/charts/cilium", namespace = "kube-system" },
    ]
  }
}

The same mechanism handles CSI drivers that the Flux controllers may need to mount before they can start — and lays the groundwork for an upcoming SPIFFE/SPIRE integration that we’ll have more to share about in the next releases. Prerequisites are also adopted by Flux for steady-state reconciliation — same handoff as above.

Migrating
