Introducing Flux Schema and the Ecosystem Catalog

Static validation for GitOps workflows with Kubernetes API server semantics, a schema catalog for the CNCF ecosystem, and a public MCP server for AI agents.
By Stefan Prodan |
Tags:

In this blog post, we introduce Flux Schema, a new Flux CLI plugin for validating Kubernetes manifests against JSON Schema and CEL rules using the same evaluation semantics as the Kubernetes API server.

Alongside the plugin, we’re announcing the Ecosystem Schema Catalog, a hosted catalog of JSON Schemas and LLM-optimized indexes covering the Kuberentes ecosystem of controllers, served to CI pipelines over CDN and to AI agents over MCP.

Why Another Validation Tool

The GitOps workflow has a well-known blind spot: a manifest with a typo, a wrong type, or a violated CEL rule sails through git push and only fails when Flux applies it on the cluster. By then the error lives in your main branch and shows up as a failed reconciliation instead of a failed pull request.

Tools like kubeconform (which inspired this project) solved part of the problem by validating manifests against JSON Schemas offline. Flux Schema builds on that idea and extends it with the API server’s own evaluation semantics:

  • Strict schema validation: every field of every Kubernetes built-in kind and custom resource is checked. Unknown fields, wrong types, and missing required properties are reported as schema violations.
  • CEL evaluation: the x-kubernetes-validations rules embedded in CRDs are evaluated with the same engine as the Kubernetes API server. A HelmRelease missing both chart and chartRef is caught locally, not on the cluster.
  • Strict YAML decoding: duplicate keys are rejected, matching Flux behavior, and metadata names, namespaces, labels, and annotations are checked against API server rules (DNS-1123, qualified names).
  • Ecosystem catalog: the ecosystem schema location resolves to schemas.fluxoperator.dev, a CDN-hosted catalog for over a hundred Cloud Native projects, extracted from upstream releases and rebuilt daily.
  • SOPS-aware: the SOPS metadata fields can be stripped before validation, so encrypted Secrets are checked without decryption.

Getting Started

Install the plugin with the Flux CLI:

flux plugin install schema

Validate a directory tree against the built-in catalog:

flux schema validate ./manifests

You can also validate rendered kustomize overlays and Helm charts, the same manifests Flux sees at reconciliation time:

kustomize build ./clusters/production | flux schema validate --verbose

helm template ./charts/app | flux schema validate -v --skip-missing-schemas

The output pinpoints each violation with its JSON path, ready to act on:

$ flux schema validate ./manifests

manifests/releases.yaml - HelmRelease/apps/frontend is invalid: cel violation
  - /spec: Invalid value: either 'chart' or 'chartRef' must be set
manifests/sources.yaml - Bucket/apps/frontend-config is invalid: schema violation
  - /spec: missing property 'bucketName'
  - /spec/interval: got number, want string
  - /spec: additional properties 'force' not allowed
Summary: 5 resources found in 2 files - Valid: 3, Invalid: 2, Skipped: 0

By default, only the invalid documents are printed; pass --verbose to also list the valid and skipped ones.

For your own in-house CRDs, you can extract JSON Schemas straight from your cluster and layer them on top of the built-in catalog:

kubectl get crds -o yaml | flux schema extract crd -d ./my-catalog

flux schema validate ./manifests \
  --schema-location ./my-catalog \
  --schema-location default

The Ecosystem Schema Catalog

The Ecosystem Schema Catalog is a hosted catalog of JSON Schemas and refreshed daily from upstream stable releases. It currently covers 100 projects and close to 9000 schemas: Kubernetes and OpenShift built-ins, all CNCF projects, and the cloud provider operators for AWS, Azure, and GCP.

The catalog is served from Cloudflare’s global network, where you can also search and browse every project and schema. The CLI reaches it through the ecosystem schema location:

flux schema validate ./manifests -s ecosystem

The catalog also keeps versioned snapshots for the six most recent minor releases of Kubernetes, OpenShift, and Flux, so validation can be pinned to the minors your clusters run. Schema locations resolve in order, so put the pinned minors first and the ecosystem catalog last as the fallback:

flux schema validate ./manifests \
  -s https://schemas.fluxoperator.dev/catalog/versions/kubernetes/v1.35 \
  -s https://schemas.fluxoperator.dev/catalog/versions/flux/v2.8 \
  -s ecosystem

Explaining Fields Without a Cluster

Backed by the ecosystem catalog, the explain command is like kubectl explain without a cluster at hand.

$ flux schema explain -s ecosystem hr.spec.dependsOn

GROUP:      helm.toolkit.fluxcd.io
KIND:       HelmRelease
VERSION:    v2

FIELD: dependsOn <[]Object>

DESCRIPTION:
    DependsOn may contain a DependencyReference slice with references to
    HelmRelease resources that must be ready before this HelmRelease can be
    reconciled.
...

Add --recursive to print nested fields, and --api-version to pick a specific group/version when a kind is served by more than one.

Shifting Validation Left in CI

Running Flux Schema in CI catches violations in pull requests before they reach the cluster. For GitHub repositories, two composite actions cover the whole pipeline: one installs the CLI, the other detects kustomize overlays and Helm charts, renders them, and validates every document against the catalog.

name: flux-schema

on:
  pull_request:
    branches: [main]

jobs:
  validate:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout
        uses: actions/checkout@v7
      - name: Setup Flux with Schema plugin
        uses: fluxcd/flux2/action@main
        with:
          plugins: |
            schema
      - name: Validate manifests
        uses: fluxcd/flux-schema/actions/validate@main
        with:
          helm-charts: "true"

A .fluxschema.yml file at the repository root makes the validation config reproducible across local machines and CI:

apiVersion: schema.plugin.fluxcd.io/v1beta1
kind: Config
validate:
  schemaLocation:
    - ecosystem

A Feedback Loop for AI Agents

The second audience for Flux Schema is AI agents. Anyone who has asked an AI assistant to generate Flux manifests knows the failure mode: the YAML looks plausible, the field names are almost right, and the error only surfaces when the manifest hits the cluster.

Agents thrive when they can verify their own work. For code, that feedback loop is the compiler and the test suite. For Kubernetes manifests, the only authoritative validator is the API server, so agents either dry-run apply manifests to a live cluster (risky, requires credentials) or skip verification entirely.

Flux Schema gives agents the API server’s judgment as a local, read-only, instant operation. The agent generates a manifest, runs flux schema validate, reads the violations with their JSON paths, fixes them, and repeats until the output is clean. Structured reports in JSON or YAML make the results machine-parseable:

flux schema validate ./manifests -s ecosystem -o json

Because the catalog is refreshed daily from upstream releases, agents validate against the current APIs rather than the versions frozen into their training data.

An MCP Server as a Public Good

Validation tells an agent that a manifest is wrong; to write it correctly in the first place, the agent needs to look up the real schema instead of reconstructing it from training data. For that, the ecosystem catalog is exposed as a remote MCP server. The MCP is a free public service operated by the Flux Operator team, with no authentication or API key required:

https://schemas.fluxoperator.dev/mcp

Think of it as an LLM-friendly kubectl explain for the whole Kubernetes ecosystem with no cluster required.

Connecting an agent takes one command. For Claude Code:

claude mcp add --transport http flux-schema-catalog https://schemas.fluxoperator.dev/mcp

For Codex:

codex mcp add flux-schema-catalog --url https://schemas.fluxoperator.dev/mcp

And for other MCP clients (Cursor, VS Code, Windsurf, …), add the server to the project’s .mcp.json:

{
  "mcpServers": {
    "flux-schema-catalog": {
      "type": "http",
      "url": "https://schemas.fluxoperator.dev/mcp"
    }
  }
}

We measured the impact by giving the same agent four tasks against recently shipped CRDs: two field lookups, one manifest to write, and one manifest review with planted errors. From training data alone, the agent got one task of four right; it invented enum values and flagged valid fields as errors. With the MCP server it scored four of four, using 57% fewer tokens and 80% fewer tool calls than achieving the same score with web search. Smaller models depend on the catalog even more: Haiku scored zero of four from memory and four of four with the MCP server, at a quarter of the web-search cost.

See the AI agents guide for the full benchmark details and per-client setup instructions.

Repository Discovery for Agents

Validation and schema lookup are still only part of what an agent needs. Before generating or auditing anything, an agent has to understand the repository it landed in, and GitOps repos are hostile to tree and grep exploration: file names like sync.yaml and release.yaml reveal nothing, multi-document files hide resources, and grepping for kind: HelmRelease matches kustomize patch files.

The flux schema discover command replaces that read-and-grep loop with one deterministic pass:

flux schema discover ./my-gitops-repo -o json

The scan is purely static (no kustomize builds, no Helm rendering, no cluster access) and emits a structured inventory designed for AI agents:

  • Directory classification: every directory is typed as plain Kubernetes manifests, a kustomize overlay, a Helm chart, or a Terraform module, so the repository pattern reads at a glance.
  • Flux resources by file: every Flux resource is listed with its defining file and namespace/name identity, so an agent opens exactly the files relevant to the task.
  • Resource census by API version: everything is counted per apiVersion/kind, so deprecated API versions stand out without reading a single manifest.
  • Context-budgeted output: plain Kubernetes resources appear as counts (2,000 Deployments cost a few lines, not thousands), and Helm chart and Terraform subtrees are pruned. A typical repository results in a few KBs.

Like the validation report, the inventory is a versioned JSON envelope with a published schema, so agents parse it programmatically instead of interpreting ad-hoc shell output.

Powering the Flux AI Skills

Flux Schema is the engine behind the official GitOps Agent Skills.

The gitops-repo-audit skill turns an AI assistant into a GitOps repository auditor. Its discovery phase runs flux schema discover to build the inventory, and its validation phase runs flux schema validate on both raw manifests and rendered kustomize output. The skill also ships the Flux OpenAPI schemas, so the agent verifies exact field names before recommending any YAML change instead of guessing from memory.

You can install the skills in your GitOps repository with the Flux Operator CLI, which verifies the cosign signature of the OCI artifact:

flux plugin install operator

flux operator skills install ghcr.io/fluxcd/agent-skills

For Claude Code and Codex you can install from the marketplace:

/plugin marketplace add fluxcd/agent-skills
/plugin install gitops-skills@fluxcd

Then ask your assistant to “audit this GitOps repo” and watch it work through discovery, validation, API compliance, best practices, and security review, with every claim grounded in the flux-schema output rather than hallucinated.

Get Involved

The ecosystem catalog grows with the community: if a project you rely on is missing from schemas.fluxoperator.dev, request it by opening an issue, and it will be picked up by the daily rebuilds once added.
